BgpSandeshContext Struct Reference

#include <bgp_sandesh.h>

Inheritance diagram for BgpSandeshContext:

Collaboration diagram for BgpSandeshContext:

Public Types
typedef boost::function< bool(const BgpSandeshContext *, bool, uint32_t, uint32_t, const std::string &, const std::string &, std::vector < BgpNeighborResp > *, std::string *)>	NeighborListExtension
typedef boost::function< void(size_t *, const BgpSandeshContext *, const ShowNeighborStatisticsReq *)>	NeighborStatisticsExtension
typedef boost::function< void(const BgpSandeshContext *, const ShowBgpPeeringConfigReq *)>	PeeringReqHandler
typedef boost::function< void(const BgpSandeshContext *, const ShowBgpPeeringConfigReqIterate *)>	PeeringReqIterateHandler

Public Member Functions
	BgpSandeshContext ()
void	SetNeighborShowExtensions (const NeighborListExtension &show_neighbor, const NeighborStatisticsExtension &show_neighbor_statistics)
void	SetPeeringShowHandlers (const PeeringReqHandler &show_peering_req_handler, const PeeringReqIterateHandler &show_peering_req_iterate_handler)
bool	ShowNeighborExtension (const BgpSandeshContext *bsc, bool summary, uint32_t page_limit, uint32_t iter_limit, const std::string &start_neighbor, const std::string &search_string, std::vector< BgpNeighborResp > *list, std::string *next_neighbor) const
void	ShowNeighborStatisticsExtension (size_t *count, const ShowNeighborStatisticsReq *req) const
void	PeeringShowReqHandler (const ShowBgpPeeringConfigReq *req)
void	PeeringShowReqIterateHandler (const ShowBgpPeeringConfigReqIterate *req_iterate)
bool	test_mode () const
void	set_test_mode (bool test_mode)
uint32_t	page_limit () const
void	set_page_limit (uint32_t page_limit)
uint32_t	iter_limit () const
void	set_iter_limit (uint32_t iter_limit)
Public Member Functions inherited from SandeshContext
virtual	~SandeshContext ()

Public Attributes
BgpServer *	bgp_server
BgpXmppChannelManager *	xmpp_peer_manager

Private Attributes
bool	test_mode_
uint32_t	page_limit_
uint32_t	iter_limit_
NeighborListExtension	show_neighbor_ext_
NeighborStatisticsExtension	show_neighbor_statistics_ext_
PeeringReqHandler	show_peering_req_handler_
PeeringReqIterateHandler	show_peering_req_iterate_handler_

Additional Inherited Members
Protected Member Functions inherited from SandeshContext
	SandeshContext ()

Detailed Description

Definition at line 23 of file bgp_sandesh.h.

Member Typedef Documentation

typedef boost::function<bool(const BgpSandeshContext *, bool, uint32_t, uint32_t, const std::string &, const std::string &, std::vector<BgpNeighborResp> *, std::string *)> BgpSandeshContext::NeighborListExtension

Definition at line 26 of file bgp_sandesh.h.

typedef boost::function<void(size_t *, const BgpSandeshContext *, const ShowNeighborStatisticsReq *)> BgpSandeshContext::NeighborStatisticsExtension

Definition at line 29 of file bgp_sandesh.h.

typedef boost::function<void(const BgpSandeshContext *, const ShowBgpPeeringConfigReq *)> BgpSandeshContext::PeeringReqHandler

Definition at line 32 of file bgp_sandesh.h.

typedef boost::function<void(const BgpSandeshContext *, const ShowBgpPeeringConfigReqIterate *)> BgpSandeshContext::PeeringReqIterateHandler

Definition at line 34 of file bgp_sandesh.h.

Constructor & Destructor Documentation

BgpSandeshContext::BgpSandeshContext

(

)

Definition at line 654 of file bgp_sandesh.cc.

Member Function Documentation

uint32_t BgpSandeshContext::iter_limit ( ) const

inline

Definition at line 65 of file bgp_sandesh.h.

uint32_t BgpSandeshContext::page_limit ( ) const

inline

Definition at line 63 of file bgp_sandesh.h.

void BgpSandeshContext::PeeringShowReqHandler

(

const ShowBgpPeeringConfigReq *

req

)

Definition at line 694 of file bgp_sandesh.cc.

void BgpSandeshContext::PeeringShowReqIterateHandler

(

const ShowBgpPeeringConfigReqIterate *

req_iterate

)

Definition at line 704 of file bgp_sandesh.cc.

void BgpSandeshContext::set_iter_limit ( uint32_t  iter_limit )

inline

Definition at line 66 of file bgp_sandesh.h.

Here is the call graph for this function:

void BgpSandeshContext::set_page_limit ( uint32_t  page_limit )

inline

Definition at line 64 of file bgp_sandesh.h.

Here is the call graph for this function:

void BgpSandeshContext::set_test_mode ( bool  test_mode )

inline

Definition at line 62 of file bgp_sandesh.h.

Here is the call graph for this function:

void BgpSandeshContext::SetNeighborShowExtensions	(	const NeighborListExtension &	show_neighbor,
		const NeighborStatisticsExtension &	show_neighbor_statistics
	)

Definition at line 662 of file bgp_sandesh.cc.

void BgpSandeshContext::SetPeeringShowHandlers	(	const PeeringReqHandler &	show_peering_req_handler,
		const PeeringReqIterateHandler &	show_peering_req_iterate_handler
	)

Definition at line 687 of file bgp_sandesh.cc.

bool BgpSandeshContext::ShowNeighborExtension	(	const BgpSandeshContext *	bsc,
		bool	summary,
		uint32_t	page_limit,
		uint32_t	iter_limit,
		const std::string &	start_neighbor,
		const std::string &	search_string,
		std::vector< BgpNeighborResp > *	list,
		std::string *	next_neighbor
	)		const

Definition at line 669 of file bgp_sandesh.cc.

void BgpSandeshContext::ShowNeighborStatisticsExtension	(	size_t *	count,
		const ShowNeighborStatisticsReq *	req
	)		const

Definition at line 680 of file bgp_sandesh.cc.

bool BgpSandeshContext::test_mode ( ) const

inline

Definition at line 61 of file bgp_sandesh.h.

Member Data Documentation

BgpServer* BgpSandeshContext::bgp_server

Definition at line 46 of file bgp_sandesh.h.

uint32_t BgpSandeshContext::iter_limit_

private

Definition at line 71 of file bgp_sandesh.h.

uint32_t BgpSandeshContext::page_limit_

private

Definition at line 70 of file bgp_sandesh.h.

NeighborListExtension BgpSandeshContext::show_neighbor_ext_

private

Definition at line 72 of file bgp_sandesh.h.

NeighborStatisticsExtension BgpSandeshContext::show_neighbor_statistics_ext_

private

Definition at line 73 of file bgp_sandesh.h.

PeeringReqHandler BgpSandeshContext::show_peering_req_handler_

private

Definition at line 74 of file bgp_sandesh.h.

PeeringReqIterateHandler BgpSandeshContext::show_peering_req_iterate_handler_

private

Definition at line 75 of file bgp_sandesh.h.

bool BgpSandeshContext::test_mode_

private

Definition at line 69 of file bgp_sandesh.h.

BgpXmppChannelManager* BgpSandeshContext::xmpp_peer_manager

Definition at line 47 of file bgp_sandesh.h.

---

The documentation for this struct was generated from the following files:

• bgp_sandesh.h
• bgp_sandesh.cc
