McastTreeManager Class Reference

#include <bgp_multicast.h>

Collaboration diagram for McastTreeManager:

Classes
class	DeleteActor

Public Types
enum	NodeLevel { LevelFirst = 0, LevelNative = 0, LevelLocal = 1, LevelCount = 2 }
typedef std::vector < McastManagerPartition * >	PartitionList
typedef PartitionList::const_iterator	const_iterator

Public Member Functions
	McastTreeManager (ErmVpnTable *table)
virtual	~McastTreeManager ()
const_iterator	begin () const
const_iterator	end () const
virtual void	Initialize ()
virtual void	Terminate ()
McastManagerPartition *	GetPartition (int part_id)
const McastManagerPartition *	GetPartition (int part_id) const
virtual UpdateInfo *	GetUpdateInfo (ErmVpnRoute *route)
DBTablePartBase *	GetTablePartition (size_t part_id)
ErmVpnTable *	table ()
const ErmVpnTable *	table () const
void	ManagedDelete ()
void	Shutdown ()
bool	MayDelete () const
void	RetryDelete ()
LifetimeActor *	deleter ()
const LifetimeActor *	deleter () const
bool	deleted () const
const ErmVpnRoute *	GetGlobalErmVpnTreeMvpnRoute () const
virtual ErmVpnRoute *	GetGlobalTreeRootRoute (const Ip4Address &source, const Ip4Address &group) const
void	NotifyForestNode (int part_id, const Ip4Address &source, const Ip4Address &group)
virtual bool	GetForestNodePMSI (ErmVpnRoute *rt, uint32_t *label, Ip4Address *address, std::vector< std::string > *encap) const

Static Public Attributes
static const int	kDegree = 4

Private Member Functions
void	AllocPartitions ()
void	FreePartitions ()
void	TreeNodeListener (McastManagerPartition *partition, ErmVpnRoute *route)
void	TreeResultListener (McastManagerPartition *partition, ErmVpnRoute *route)
void	RouteListener (DBTablePartBase *tpart, DBEntryBase *db_entry)
	DISALLOW_COPY_AND_ASSIGN (McastTreeManager)

Private Attributes
ErmVpnTable *	table_
int	listener_id_
PartitionList	partitions_
boost::scoped_ptr< DeleteActor >	deleter_
LifetimeRef< McastTreeManager >	table_delete_ref_

Friends
class	BgpMulticastTest
class	ShowMulticastManagerDetailHandler

Detailed Description

Definition at line 384 of file bgp_multicast.h.

Member Typedef Documentation

typedef PartitionList::const_iterator McastTreeManager::const_iterator

Definition at line 389 of file bgp_multicast.h.

typedef std::vector<McastManagerPartition *> McastTreeManager::PartitionList

Definition at line 388 of file bgp_multicast.h.

Member Enumeration Documentation

enum McastTreeManager::NodeLevel

Enumerator
LevelFirst
LevelNative
LevelLocal
LevelCount

Definition at line 391 of file bgp_multicast.h.

Constructor & Destructor Documentation

McastTreeManager::McastTreeManager ( ErmVpnTable *  table )

explicit

Definition at line 871 of file bgp_multicast.cc.

McastTreeManager::~McastTreeManager ( )

virtual

Definition at line 881 of file bgp_multicast.cc.

Member Function Documentation

void McastTreeManager::AllocPartitions ( )

private

Definition at line 907 of file bgp_multicast.cc.

Here is the call graph for this function:

const_iterator McastTreeManager::begin ( ) const

inline

Definition at line 401 of file bgp_multicast.h.

bool McastTreeManager::deleted

(

)

const

Definition at line 1123 of file bgp_multicast.cc.

LifetimeActor * McastTreeManager::deleter

(

)

Definition at line 1108 of file bgp_multicast.cc.

const LifetimeActor * McastTreeManager::deleter

(

)

const

Definition at line 1116 of file bgp_multicast.cc.

McastTreeManager::DISALLOW_COPY_AND_ASSIGN ( McastTreeManager  )

private

const_iterator McastTreeManager::end ( ) const

inline

Definition at line 402 of file bgp_multicast.h.

void McastTreeManager::FreePartitions ( )

private

Definition at line 916 of file bgp_multicast.cc.

bool McastTreeManager::GetForestNodePMSI ( ErmVpnRoute *  rt, uint32_t *  label, Ip4Address *  address, std::vector< std::string > *  encap  ) const

virtual

Definition at line 1139 of file bgp_multicast.cc.

Here is the call graph for this function:

const ErmVpnRoute* McastTreeManager::GetGlobalErmVpnTreeMvpnRoute

(

)

const

ErmVpnRoute * McastTreeManager::GetGlobalTreeRootRoute ( const Ip4Address &  source, const Ip4Address &  group  ) const

virtual

Definition at line 1127 of file bgp_multicast.cc.

Here is the call graph for this function:

McastManagerPartition * McastTreeManager::GetPartition

(

int

part_id

)

Definition at line 923 of file bgp_multicast.cc.

const McastManagerPartition * McastTreeManager::GetPartition

(

int

part_id

)

const

Definition at line 927 of file bgp_multicast.cc.

DBTablePartBase * McastTreeManager::GetTablePartition

(

size_t

part_id

)

Definition at line 934 of file bgp_multicast.cc.

Here is the call graph for this function:

UpdateInfo * McastTreeManager::GetUpdateInfo ( ErmVpnRoute *  route )

virtual

Definition at line 942 of file bgp_multicast.cc.

Here is the call graph for this function:

void McastTreeManager::Initialize ( )

virtual

Definition at line 888 of file bgp_multicast.cc.

Here is the call graph for this function:

void McastTreeManager::ManagedDelete

(

)

Definition at line 1092 of file bgp_multicast.cc.

bool McastTreeManager::MayDelete

(

)

const

Definition at line 1069 of file bgp_multicast.cc.

void McastTreeManager::NotifyForestNode	(	int	part_id,
		const Ip4Address &	source,
		const Ip4Address &	group
	)

Definition at line 1133 of file bgp_multicast.cc.

Here is the call graph for this function:

void McastTreeManager::RetryDelete

(

)

Definition at line 1099 of file bgp_multicast.cc.

Here is the call graph for this function:

void McastTreeManager::RouteListener ( DBTablePartBase *  tpart, DBEntryBase *  db_entry  )

private

Definition at line 1051 of file bgp_multicast.cc.

Here is the call graph for this function:

void McastTreeManager::Shutdown

(

)

Definition at line 1084 of file bgp_multicast.cc.

ErmVpnTable* McastTreeManager::table ( )

inline

Definition at line 412 of file bgp_multicast.h.

const ErmVpnTable* McastTreeManager::table ( ) const

inline

Definition at line 413 of file bgp_multicast.h.

void McastTreeManager::Terminate ( )

virtual

Definition at line 899 of file bgp_multicast.cc.

Here is the call graph for this function:

void McastTreeManager::TreeNodeListener ( McastManagerPartition *  partition, ErmVpnRoute *  route  )

private

Definition at line 962 of file bgp_multicast.cc.

Here is the call graph for this function:

void McastTreeManager::TreeResultListener ( McastManagerPartition *  partition, ErmVpnRoute *  route  )

private

Definition at line 1011 of file bgp_multicast.cc.

Here is the call graph for this function:

Friends And Related Function Documentation

friend class BgpMulticastTest

friend

Definition at line 432 of file bgp_multicast.h.

friend class ShowMulticastManagerDetailHandler

friend

Definition at line 433 of file bgp_multicast.h.

Member Data Documentation

boost::scoped_ptr<DeleteActor> McastTreeManager::deleter_

private

Definition at line 449 of file bgp_multicast.h.

const int McastTreeManager::kDegree = 4

static

Definition at line 386 of file bgp_multicast.h.

int McastTreeManager::listener_id_

private

Definition at line 446 of file bgp_multicast.h.

PartitionList McastTreeManager::partitions_

private

Definition at line 447 of file bgp_multicast.h.

ErmVpnTable* McastTreeManager::table_

private

Definition at line 445 of file bgp_multicast.h.

LifetimeRef<McastTreeManager> McastTreeManager::table_delete_ref_

private

Definition at line 450 of file bgp_multicast.h.

---

The documentation for this class was generated from the following files:

• bgp_multicast.h
• bgp_multicast.cc
